Aluminium 6061 Light guide fixture plate

1. Product Introduction

Designed with concentric locating rings, square mounting flange and multi-spec positioning holes, it guarantees uniform film coating for optical light-conducting parts. The brushed & passivated surface features low vacuum outgassing and long reusable lifespan. Custom sizes and lug structures are acceptable to fit various optical coating equipment.

Advantages of the material aluminum 6061：

• Low outgassing rate: No volatile impurities in the high vacuum coating chambers, effectively preventing the contamination of film layers;
• High thermal conductivity and dimensional stability: No deformation under long-term high temperature coating cycles;
• Light weight and high rigidity: Easy to be mounted and rotated on the spindles of the coating machine, reducing the equipment load;
• Excellent reusability: No corrosion after repeated chemical cleaning, long service life.

2. Product Parameter (Specification)

Production Name	Aluminium 6061 Light guide fixture plate
Material Capabilities	Aluminium 6061
Brand	LIONSE
Surface Treatment	Black Oxide
Origin	Qingdao, China

3. Product Details

4.Precision Machining Features

• Concentric multi-ring positioning grooves

       Multi-layer stepped circular trenches are precisely CNC turned, ensuring light guide parts are evenly laid without offset, delivering consistent coating thickness on every workpiece.

• Multi-functional hole layout

       Corner through mounting holes: Fast locking onto machine brackets;

       Surface locating holes & threaded holes: Secure pressure clips to fix workpieces without scratching light-transmitting surfaces;

       Central hollow hole: Unobstructed light path for evaporation and ion source during coating.

• High geometric accuracy

       Strictly controlled concentricity ≤0.02mm and ultra-flat bearing surface, eliminating tilting of optical components. All sharp edges are deburred with tiny R0.2 fillets to avoid scratches on fragile light guides.
